Fast, accurate and cost-effective establishment of solar systems in any area.
Load table for calculations - for engineers and soil consultants
Types of ground screws - and foundation capabilities
Data table: types of screws according to diameter/length and carrying capacity.
Pull/load test
Despite the theoretical data regarding the use load capacity of the screws (according to the tables and soil data), it is recommended to perform a capacity test on site, easily and quickly - in order to give the planner the capacity data of the screws - in the area cell specific to the project. The test is usually done by the testing facility the ability of the screw to resist pulling out, by a hydraulic lever and a digital weight connected to the installed screw. The figure we get is divided in half, just to be safe. For example: a screw whose pull-out resistance is 2,200 kg, will be recommended by us for a load of up to 1,100 kg (approx. 1 ton). The test is super accurate, and relevant to the area of land where it was performed. In large areas, I perform a number of tests in several areas - in order to make the findings accurate.
Israeli standard 918
Standard 918: Hot-dip zinc coating on steel products and iron casting products. The standard applies to hot-dip zinc plating. Our ground screws and the related products are manufactured subject to the European and American standards, and are also sent to laboratory tests in Israel, to obtain the Israeli standard 918, at Xenon Laboratories Ltd. You can see in the attached reports that the galvanization levels of the screws are more than double the standard's requirements.
Load and pull test
Load testing and pull-out testing are necessary to match the type of bolt: length, diameter, and helix type to the project. The test is performed by us, after installing a trial bolt/bolts. The data we receive is the weight-bearing load of each bolt, and the ability to resist pull-out. This data will allow the project manager/constructor to match the correct bolts to the project.
Protective coating against corrosion, rust, seawater, chemicals and more
https://linex.co.il/line-x/ Line-x allows you to create a unique protective coating for ground screws and constructions - and allows for widespread use even in areas and soils that may damage metals over time.
Immediate foundation, simple for self-installation, suitable for pergola posts, deck or balcony stabilization, mailboxes, signage, garden furniture, hammocks and much more...
₪169₪139
Ground screw with extremely high carrying capacity, 76 mm in diameter, 3 mm wall thickness. Suitable for solar panels, thin panels, bridges, garden sheds, wooden houses, traffic signs, charging stations and more.
₪235
Ground screw for professional uses, 180 cm long, 200 mm diameter steel plate with holes adjusted for universal connection.
₪340
Ground screw for specialized tasks - supporting buildings, constructive installations that require stability and resistance to loads of over 8 tons. The screws are made of high-carbon steel type S235 and S355 - stronger and more durable in harsh climate conditions. The screws are manufactured in sections of 3 or 2 meters per unit, allowing for lengths of up to 10 m. Load-bearing capacity of up to 15 tons per unit with a length of 5 m, depending on the type of soil. In the photos - screws ordered for a project on a riverbank. Production on demand includes 110 micron galvanization + epoxy coating in a color chosen by the customer.
₪2200
A pull-out test device up to 4 tons will allow you to perform an immediate pull-out test on an installed bolt: a measure of the specific bolt's ability in the soil designated for the project to withstand pull-out and withstand winds and constructive forces. The test is simple and immediate - and will help you choose the right bolts for your project. Do not compromise on a bolt that does not provide enough, nor do you invest in bolts with a higher capacity than required. The device will allow you to obtain approval from the engineer / constructor, and choose the appropriate bolt.
₪9800
A pull-out test device up to 4 tons will allow you to perform an immediate pull-out test on an installed bolt: a measure of the specific bolt's ability in the soil designated for the project to withstand pull-out and withstand winds and constructive forces. The test is simple and immediate - and will help you choose the right bolts for your project. Do not compromise on a bolt that does not provide enough, nor do you invest in bolts with a higher capacity than required. The device will allow you to obtain approval from the engineer / constructor, and choose the appropriate bolt.
₪6200
